Voltage & current dividers practice problems
Refresh the page to get a new problem.
Read the voltage and current divider class notes.
For the circuit shown,
- R1 = 22 Ω
- R2 = 82 Ω
- R3 = 10 Ω
- VS = 25 V
Use the voltage divider method to find vR3.
