RC transients practice problems
Refresh the page to get a new problem.

Read the RC-transient class notes.

For the circuit shown,

• R = 3.3 kΩ
• C = 3.3 nF

For the RC circuit, the source voltage has been at an initial voltage of V_i = -20 V for a long time. At t = 0, the source voltage abruptly jumps to V_f = 25 V.

Determine the expression for the capacitor voltage as a function of time, for t > 0.

Calculate the capacitor voltage and capacitor current at t = 21.78 μs.

Answer
