Source transformation practice problems
Refresh the page to get a new problem.
Read the source-transformation class notes.
For the circuit shown,
- R1 = 56 Ω
- R2 = 82 Ω
- R3 = 27 Ω
- VS1 = 24 V
- VS2 = 13 V
Use the source transformation method to find vR1.
