Thevenin & Norton practice problems
Refresh the page to get a new problem.
Read the Thevenin-Norton class notes.
For the circuit shown,
- R1 = 22 Ω
- R2 = 56 Ω
- R3 = 39 Ω
- R4 = 68 Ω
- VS = 5 V
Find the Norton equivalent of the circuit at the port defined by the nodes a and b.
